Article number: 1457640
TECHNICAL DATA
Setting force: 20,000 N
Weight: 2.1 kg with battery
Drive: 18 V brushless DC motor (BLDC)
Stroke: 25 mm
SCOPE OF DELIVERY
Nosepieces: 17/32, 17/36, 17/40 and 17/45
Additional jaw pusher for smaller blind-rivet
dimensions (Required nosepieces page 136)
WORKING RANGE
Blind rivets up to Ø 6.4 mm all materials and up to
Ø 8 mm aluminium. BULB-TITE® blind rivets up to
Ø 7.7 mm all materials. MEGA GRIP® and G-Bulb
blind rivets up to Ø 6.4 mm all materials.
(max. mandrel Ø 4.3 mm)
ADVANTAGES
Even more powerful: Thanks to the brushless
motor and the 20,000 N setting force the PowerBird®
Pro Gold Edition is even more powerful and can even
set G-Bulb and PolyGrip® blind rivets up to Ø 6.4 mm
in any material. The optional Autoreverse function
additionally shortens the pulling process, ensuring the
PowerBird® Pro Gold Edition is immediately ready for
operation. The stroke has been substantially increased
to 25 mm for the purpose of setting particularly long
rivets.
Even faster, virtually no wear: Since no wearprone
brushes are use, the motor of the PowerBird® Pro
Gold Edition has an extremely long service life, is
virtually non-wearing and and reliably guarantees the
fastest setting frequencies.
Well-proven and ergonomically designed:
The PowerBird® Pro Gold Edition is equipped with the
low-wear jaws system and features the same ergonomic
design as the TAURUS® series, already proven a
thousand times over.
MADE IN GERMANY
Tools and fasteners that are
Made in Germany. At our three
German locations, we manufacture
top-quality blind rivets
and setting tools for international
demand.
What Is A Blind Rivet?
A blind rivet consists of two parts: the hollow rivet and the mandrel body. The hollow rivet has a setting head and a rivet body. The setting head is located on the processing side and is available with a range of diameters and in different forms. The head variants are as follows: dome head, countersunk and large flange. The rivet body comes in different lengths that will depend on the thickness of the material to be riveted. The job of the mandrel body is to deform the rivet body. It has a predetermined breaking point, at which the mandrel body breaks off once the rivet has been deformed sufficiently. The filling section is the portion of the mandrel body that is left behind in the hollow rivet. The spent mandrel is the portion of the mandrel body that is removed from the set rivet using the blind riveting tool and disposed of.
How To Installing?
During the setting process, the mandrel body is moved using the setting tool jaws, deforming the hollow rivet until it is firmly positioned in the component as predefined. In the end, the mandrel body breaks off at the specified point (the predetermined breaking point) and can be disposed of via the recycling system. The rest mandrel is the spent mandrel left behind in the hollow rivet and can provide an additional locking function depending on the application in question.
